Tiny boards for big projects

Raspberry Pi CM5 TV Stick

Raspberry Pi CM5 that plugs directly to TV/monitor

Specs:

Compatible with Raspberry Pi CM5 Lite and eMMC variants
HDMI plug
Micro SD card connector
USB-C connector for data/power
Two USB3.0 USB-A connectors
IR receiver
User button
Power button
RPI_nBOOT button for CM5 eMMC programming
Fan connector
Power and Act LEDs
Connector for Ambilight-like lightning with WS2812 or WS2801 LEDs (GND, GPIO18, GPIO10 and GPIO11)

More info on GitHub

Order now!

Raspberry Pi CM0IQ

Tiniest Raspberry Pi board, measuring just 42x36mm!

CM0IQ board is based on Raspberry Pi/EDATEC CM0 Compute module

Specs:

Raspberry Pi CM0 Lite
1GHz quad-core 64-bit Arm Cortex-A53 processor
512MB SDRAM
H.264/MPEG-4 video decoding, 1080p@30fps
H.264 encoding, 1080p@30fps
WiFi with extermal antenna connector
USB type-C for power and gadget mode
USB-A
HDMI type D (micro HDMI)
DSI 4-lane
CSI 4-lane
40-pin GPIO connector, 1.27mm pitch
SD-card holder
5V solder pads
M2 x4 standoffs for mounting the board

More info on GitHub

Order now!

Raspberry Pi CM4 TV Stick

Raspberry Pi CM4 that plugs directly to TV/monitor

Specs:

compatible with Raspberry Pi CM4 eMMC and no-eMMC
HDMI plug
micro SD card connector
USB-C connector
Two USB2.0 USB-A connectors
USB2.0 as solder pads on reverse side
IR receiver on GPIO17
User button on GPIO14 (also tied to nRPIBOOT: hold on power on to enter USB MSD mode for eMMC programming/fw update)
USB multiplexer selector switch: enable 2xUSB-A ports or CM4 USB device mode
Power and Act LEDs
14 GPIOs, as well as GND, 5V and 3.3V solder pads on reverse side of PCB for hacking
Connector for Ambilight-like lightning with WS2812 or WS2801 LEDs (GND, GPIO18, GPIO10 and GPIO11)

More info on GitHub

Order now!

Dual Edge TPU Adapter for multiple TPU cards

PCIe x4 card to host 2 Dual Edge TPUs

Order now!

Dual Edge TPU Adapter - PCIe x1 Low Profile

Dual Edge TPU Adapter is designed for Coral m.2 Accelerator with Dual Edge TPU to be used on a system with PCIe x1 slot available

More info on GitHub

Order now!

Dual Edge TPU Adapter - m.2 2280 B+M key

Dual Edge TPU Adapter is designed for Coral m.2 Accelerator with Dual Edge TPU to be used on a system with m.2 2280 B- or M-key slot available

Important: this adapter requires PCIe interface and will not work with:

SATA m.2 slots
External USB to m.2 enclosures, including m.2 NVMe encosures
Raspberry Pi Compute Module 4

More info on GitHub

Order now!
